## 5 Top DeepEX Features

✓ Design any Excavation in Minutes with all Construction Stages

✓ Structural & Geotechnical Design of Excavations in a Single Suite

✓ Limit Equilibrium, Non-Linear Analysis, Finite Element Methods

✓ Analyze 2D & 3D Excavation Models, Check Steel Connections & more

✓ Review All Results in Graphs and Tables, Optimize all Structural Sections, Export Sketches & Reports & more

ALL-IN-1 Suite, Packed with Knowledge, Sided with Great Technical Support,

## An Example Why DeepEX Would be Valuable for your Engineering Practice:

Selecting the appropriate surcharge method can have a significant impact in the design of any deep excavation model. Below we present the effect of different external load methods on a cantilever excavation model in the calculation of the wall embedment and the selection of the required structural section. The analysis of the models is performed with our shoring design software - DeepEX.

The following cases are evaluated:

Case 1: Distributed Surface Load – Elasticity Equations (Boussinesq etc.)

Case 2: Distributed Surface Load – 2-Way Distribution Method

Case 3: Distributed Surface Load – 1-Way Distribution Method

Case 4: Distributed Surface Load – Elasticity Equations x2 (AREMA Specifications)

Case 6: 3D Load (Footing) – Distributed Load – 2-Way Distribution from Soil Friction

Case 1 - Elasticity Equations: Wall Embedment FS, Wall Moment & Surcharge Pressure Diagrams

Case 2 - 2-Way Distribution: Wall Embedment FS, Wall Moment & Surcharge Pressure Diagrams

Case 3 - 1-Way Distribution: Wall Embedment FS, Wall Moment & Surcharge Pressure Diagrams

Case 4 - Elasticity Equations x 2: Wall Embedment FS, Wall Moment & Surcharge Pressure Diagrams

Case 5 - 3D Load Elasticity Equations: Wall Embedment FS, Wall Moment & Surcharge Pressure Diagrams

Case 6 - 1-Way Distribution from Soil Friction: Wall Embedment FS, Wall Moment & Surcharge Pressure Diagrams

Table: Optimum Wall Embedment and Structural Sections for Each Examined Method
